It can sometimes be a little bit confusing how Logic Pro organises its folders and how we should work with them. I’m going to demystify some of this in the following article.
This is where factory presets and other data is stored. This means data that Logic Pro depends upon “out of the box”. So, in here you will find numerous folders, including for example:
This folder contains organised subfolders of .exs files representing the instruments you see in the menus of the EXS24 mkII Sampler when you open it up in Logic Pro.
Here you will find the samples referred to by the EXS files.
Logic Pro’s instruments and effects plug-ins come equipped with a numerous presets as “.pst” files. This is where they’re stored.
This is where you store your own sampler instruments, plug-in settings and other customised settings (such as templates and key command sets) in the appropriate folders. Perhaps it would be particularly useful if we look at:
When you’re using a Logic Pro plug-in (including instruments) and tweak a setting, for example “Predelay” on a reverb, then go to save the setting, Logic Pro doesn’t offer you to save the setting in the same folder it was loaded from (the Factory location). Instead it offers you the equivalent location in the User level config folder.
Once you have saved a preset here it will be visible in that plug-in’s menu to be loaded again. You can define subfolders on the file system and these will be reflected in the menu.
Logic Pro should offer you this location when you wish to save instruments from the EXS24 mkII Sampler Options → Save instrument as… menu. If it doesn’t, then navigate to here.
Instruments saved here will then show up in the EXS24 mkII menu reflecting the folder structure you have defined.
As we might expect, the “EXS Factory Samples” folder is not present in the User level config folder. You store the actual samples for your instruments wherever you like – perhaps in a location from which several unrelated applications can easily load them. I store mine at /Users/Gavin/Music/Sample Libraries.
This is a system folder, as it were, and in here you will find a folder called “Apple Loops” where Logic Pro has installed all of its audio loops.
They are actually inside the subfolder Audio/Apple Loops/Apple. Also inside the Apple Loops folder (along with the “Apple” folder) is one called User Loops where shared user loops can go. But as we’ll see in a moment, you will more likely put your own loops somewhere else.
Also found in the Global Audio folder are various MIDI and device configuration folders used by OSX. Two other folders are of particular note:
This is where Logic Pro, by default, puts any plug-ins that you have installed using their installer programs. They’re placed here so that they will be available for any user. You’ll find appropriate folders for Audio Unit plug-ins (“Components”) and other formats which might have been installed even though you probably won’t use them on OSX.
All of your third-party plug-ins have been given folders in here, inside which you will probably find any factory presets (that is, presets that shipped with the plugin).
Note that there may not be any presets in here if the plugin just doesn’t have any or if the manufacturer has instead decided to place them in another custom location (possibly the /Library/Application Support folder).
You’ll find the equivalent of the Global Audio folder inside your own Library folder (access to this is restricted – go to the Finder “Go” menu, hold down “alt” and it will appear). You store loops you have made in the Apple Loops/User Loops/SingleFiles folder in here (they are actually put in this folder if you drag them onto the Apple Loops Browser within Logic Pro).
If you have purchased third-party Apple Loops then these should go, in their folders, inside the User Loops folder. They will then show up under “Other” in the Logic Pro Loops Browser. Another option (one I recommend) is to move these libraries to a central location, as suggested earlier, and instead place aliases to the folders in the User Loops folder. They will appear just the same.
Also inside the User Audio folder is:
This folder should contain all of the same subfolders as its global equivalent. When you have a plug-in window open in Logic Pro with an instrument inside it and you go to save the state of the plug-in, you’ll be offered the appropriate location here and Logic Pro will save a .aupreset file.
When you save the state of an instrument using its own menus rather than those of the Logic Pro plug-in window, the preset may well be saved in a different location and using a proprietary format. .aupreset files nonetheless do save the complete state of the instrument at the given time, so it is your choice as to which to use. In this kind of situation I generally recommend using the instrument’s own menus.
If any plug-ins were installed for the current user only, they’ll be found here, but since this will not usually be the case, you’ll probably find these folders to be empty.
That about wraps it up from me, for now, on understanding Logic’s installation paths!
